Požiadajte o cenovú ponuku

Bazénové tepelné čerpadlá

HP GREEN On/Off1400

Veľkosť bazéna
55 m³

SOLD OUT alternative HP Black 1500

4-season ON/OFF

  • Automatic cooling/heating
  • Economical fixed speed
  • Hot gas defrost is STANDARD
  • New environmentally friendly refrigerant R32
  • Available in COMPACT & SPLIT versions
  • With titanium heat exchanger for chlorine, salt and sulphur water
  • Traditional fixed speed technology at decent price

EAN CODE: 0710497754798

Kde nakúpiť
Sprievodca veľkosťami
Model
Veľkosť bazéna Letná sezóna s krytom/bez krytu
Maximálna veľkosť bazéna na zimné použitie
Vykurovací výkon leto Vzduch 27 °C, voda 27 °C
Vykurovací výkon Pružina/Autum Vzduch 15°C Voda 26°C
Vykurovací výkon zima Vzduch -15°C Voda 27°C
Chladiaci výkon Leto Vzduch 35 °C Voda 28 °C
Nastavenie teploty vody min-max
Chladenie chladiča Vzduch 40°C Voda 8°C
HP GREEN ON/OFF 1000 Ideal for 30m³ Max. pool size 45m³ 16m³ 9.2kW | 6.1 COP 6.4kW | 4.7COP 2.9kW 4.9kW +5°C ~ +45°C 2.6kW
HP GREEN ON/OFF 1400 Ideal for 30m³ Max. pool size 55m³ 25m³ 12.3 kW | 6.0 COP 8.6kW | 4.7 COP 3.7kW 6.2kW +5°C ~ +45°C 3.2kW

Not sure which Heat Pump

should you choose?
Ako si vybrať tepelné čerpadlo?

Key data

Pool size | HP GREEN On/Off - Microwell
Pool size
45 m³
Heating Output | HP GREEN On/Off - Microwell
Heating Output
9.2 kW
Cooling Output | HP GREEN On/Off - Microwell
Cooling Output
9.2 kW
COP | HP GREEN On/Off - Microwell
COP
6.1
Operating air temperature range | HP GREEN On/Off - Microwell
Operating air temperature range
-7°C to +43°C
Water temperature range | HP GREEN On/Off - Microwell
Water temperature range
+8°C to +35°C
DC compressor | HP GREEN On/Off - Microwell
DC compressor
Fixed speed AC
PV ready contact | HP GREEN On/Off - Microwell
PV ready contact
yes
Titanium exchanger | HP GREEN On/Off - Microwell
Titanium exchanger
yes - Grade 1 ASTM B264M

Customize your

Heat pump
HP 1400 GREEN Compact


Why HP Green from Microwell?

When it comes to choosing a swimming pool heat pump, the HP Green 1000 from Microwell stands out for its exceptional features and benefits. Let's delve deeper into what makes this heat pump the ideal choice for keeping your pool water at the perfect temperature all year round:

Rapid Heating for Instant Enjoyment

No one likes waiting around for their pool to heat up. With the HP Green 1000, you won't have to. Its powerful heat output ensures that your pool water reaches the desired temperature quickly, allowing you to dive in and enjoy your pool without unnecessary delays.

High Efficiency for Energy Savings

The HP Green 1000 boasts cutting-edge heat pump technology that excels in energy efficiency. By harnessing heat from the surrounding air, it transfers this warmth to your pool water with remarkable efficiency. What does this mean for you? Significant energy savings and a reduced environmental impact, all while enjoying comfortably heated water.

Discover Green

1000 ON/FF
HP 1000 GREEN On/Off

Whisper-Quiet Operation for Tranquil Relaxation

Say goodbye to noisy pool heating systems that disrupt the serenity of your outdoor oasis. The HP Green 1000 operates almost silently, preserving the peaceful ambiance of your pool area. You can relax, unwind, and enjoy your pool without the distraction of loud machinery.

User-Friendly Controls for Effortless Management

With the user-friendly control panel of the HP Green 1000, taking control of your pool's climate is a breeze. Set and adjust your desired water temperature and operating schedule with ease. You're in charge of creating the perfect pool environment tailored to your preferences.

GoldFin: Your Timeless Guardian

You ever wondered why heat pumps look blue or goldish (yellow) from the back? This the protection layers of the aluminum fins of the air exchanger. In Microwell we exclusively apply epoxy based GoldFin protection for all our products because it is just the best. GoldFin creates hydrophobic layer which repels water. In this case the heat pump in colder weather will freeze lot later than standard Bluefin and will defreeze itself faster than Bluefin. This will provide simply more heating. GoldFin is also superior in livelihood of the unit in salty air (coastal application) or sand. It will simply last longer.

Titanium Grade1 – no compromise

In Microwell we understand that livelihood of a heat pump is key factor when deciding for its purchase. Titanium Grade 1 ASTM B265M consists of at least 99.2% titanium, with small amounts of oxygen, iron and other compounds (carbon, nitrogen and hydrogen) up to 0.8%. The low impurity levels contribute to its exceptional corrosion resistance. This material also leave no trace, no odor and is neutral to its environment. All Microwell heat pumps are equipped exclusively with this type of titanium in their water exchangers.

Massive heat exchange area – up to 1.2m2

We apply extra surface of up to 1.2m2 of corrugated (twisted) titanium spiral. You can’t go around the physics, you can embrace it. The extensive heat exchange surface provides unprecedented performance and livelihood for each single Microwell heat pump.

Salt + Chlorine + UV + Electrolysis

Each Microwell heat pump is designed to work with various kinds of water, including those treated with chlorine, salt, electrolysis, sulfur or UV. This is mainly thanks to exclusive Titanium Grade1 ASTM B265M titanium tube material used inside water heat exchanger. Standard stainless steel or copper exchangers used in domestic heat pumps would typically last 1 month in pool application with water treated by chlorine. With Microwell heat pump you can be sure that materials used are designed for long harmless operations.

RS-485 Modbus

RS-485, in the context of the Modbus communication protocol, is a widely used interface for industrial control systems and automation applications. RS-485 is a standard for serial communication that allows multiple devices to communicate with each other over long distances. Each Microwell pool heat pump is equipped with RS-485 port based on ModBus protocol. You can program the heat pump to be voice-controlled and also integrated into your smart house control system. The distance to your Microwell heat pump has never been so close.

Technical data and more

If you want to know more just click


Operating on the thermodynamic principle, which is considered to be one of the most energy efficient systems for water heating or water cooling, Microwell heat pumps are capable of extracting ambient air from any environment ensuring maximum performance with an efficiency that remains unsurpassed on the market.

Microwell swimming pool heat pumps are designed for heating or cooling the water in pools and hot tubs at minimum operational costs.

HP 1400 Green is a powerful heat pump suited for pools up to 55m3 in volume.

HP 1400 Green can provide up to 12.3 kW of heating at typical seaside conditions of air temperature 27°C, water temperature 27°C and air humidity 80%.

Heat and cool with one device. Heat pump HP 1400 Green is designed for heating and cooling. The control is very simple. When you set your desired water temperature, the heat pump will automatically heat or cool to keep your desired temperature. HP 1400 Green provides with up to 6.2 kW cooling output.

Highly efficient ecological refrigerant

Reducing Global Warming & Ozone Layer Depletion by HP production The quantity of R32 refrigerant used is significantly lower as compared to the R410A refrigerant. Consequently, this results in decreasing the potential of global warming and minimal depletion of the ozone layer. That´s why Microwell developed the new generation of swimming pool heat pumps, working on the principles of R32 refrigerant with higher capacity.

High efficiency. Swimming pool heat pump is designed to compensate higher investment costs by very low operational costs compared to electric or gas heater. Microwell heat pumps are designed for a maximum efficiency reaching COP values up to 7. Efficiency of the heat pump is a ratio between power consumption (energy you pay) and actual heating or cooling output (energy you receive). With electric heater, the ratio is 1=1, i.e. what you consume and pay you get in the form of heat. Gas heaters may reach efficiency of 1.3. Heat pump’s COP of 7 means that you pay for 1kWh and you get 7kWh of energy. In cooling mode the heat pump provides with solid ratio of 4. Heat pump’s advantage is that it is independent from sun, day or night and weather. Currently the heat pump is the most efficient way of water conditioning in pools or hot tubs.

How is heat pump so efficient? Microwell HP 1400 Green heat pump is able to extract the heat/cold that is present in ambient environment and leveraged pass it into the pool water. If you take your refrigerator, it creates cold inside the fridge by releasing the heat from the back. Heat pump takes the heat (energy or calories) from ambient air and transforms it into the water. The surrounding air cools down in the process. When working in cooling mode, the excessive heat from water is passed into surrounding air. When heating, higher the ambient air temperature is, more free energy can the heat pump extract and thus reach higher efficiency. At favorable conditions you pay around 15% of heat, i.e. 85% of heat is free. Microwell heat pump is built on currently the most eco-friendly refrigerant R32.

Microwell swimming pool heat pumps provide warm pool:

  • At lowest cost possible
  • In shortest possible time
  • With lowest noise possible

HP 1400 Green is equipped with Microwell unique microECONOMY+ feature offering the most economy circulation pump control. Microwell swimming pool heat pumps can be connected to existing water system (filtration) or it can have an individual circulation pump. A swimming pool heat pump needs continuous water flow to heat or cool. HP 1400 Green tells the circulation pump when heat pump needs to heat or cool. The circulation is turned on and off according to this request. Microwell applies specially designed software that will sample the water and also put the whole system into sleep for the time when heating or cooling is not required. This saves precious energy and results in lower operational costs of the pool.

Full year heating. HP 1400 Green is also designed for a full year heating, particularly winter time. Typical winter can experience air temperatures -15°C. Heat pump thus needs to be protected against possible frost damage and equipped with systems that will keep the heat pump’s performance at desired level.

Long livelihood. Microwell swimming pool heat pumps are designed for 15+ years livelihood. The product requires minimal maintenance. You only need to ensure cleanness of air exchanger from leaves, dust and other particles.

Titanium. Amount of titanium is very important to a swimming pool heat pump. The amount talks about the actual heat transfer area, i.e. power and efficiency of each heat pump. Microwell is proudly using 40% more titanium in heat pumps’ water exchangers. This maximizes the performance and efficiency COP&EER far ahead of others. HP 1400 Green uses 0.6m2 of titanium whereas others use less than 0.25m2.

Dimensions LxWxH (mm): 1000 x 385 x 665

Microwell HP 1400 Green consumes on average 1.8 kW while heating to 12.3 kW (air temperature 27°C, water temperature 27°C, relative humidity 80%) at 32dB(A) only confirms how well designed and manufactured the pumps are.

Extra features. Microwell is continuously focusing on customers’ demands and wishes. Each heat pump is equipped with special features unique about Microwell heat pumps.

antiVIBRATION+ offering special set of mounting silent blocks eliminating excessive vibration and noise.

microECONOMY+ offering the most economical circulation pump control.

antiFREEZE+ offering non-stop antifreeze protection of your heat pump.

WINTER module allowing the pump to work down to -15°C of ambient air temperature.

Condensate tray defrost and Heat exchanger frost protection to complete the winter package and operations down to -15°C of ambient air temperature.

Typically, the unit is in stock near you. Due to many different ways the unit can be tailored on demand, it may take up to 10 days to deliver the unit to you.

If you need assistance in sizing the right heat pump for you please use our online HOW TO CHOOSE tool

Or click on SELECT THE RIGHT HEAT PUMP on the left side of your screen.

HP 1400 GREEN ON/OFF product components

Offering an in-depth look at the HP 1400 Green On/Off, explore its intricate components for a comprehensive understanding of its advanced features.


360 view

Technické údaje

Produkt
Objem bazéna (m³ / s krytom /bez krytu)
Tepelný výkon (kW / A27 / W27 / RH80%)
Tepelný výkon (kW / A15 / W26 / RH70%)
Chladiaci výkon (kW / A35 / W28 /RH80%)
COP
Elektrický výkon (kW)
Pracovná teplota (°C)
Prietok vody (m³h / kPa)
Vstupné napätie (V AC/ph)
Tepelný výmenník (Typ titánu)
Množstvo titánu (m²)
Hladina hluku (dB(A) / 1m)
Príruba na pripojenie potrubia cirkulačnej (mm /palec)
Rozmery (Š x V x H)
HP 900 BLACK Inverter
40/30
9.0
6.6
4.9
10.6-5.8
0.2-1.6
-7°C...+43°C
2.7
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.4
49
50
932x609x377
HP 1000 GREEN On-Off
45/30
9.2
6.4
4.9
4.7-6.1
1.4
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
4
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.42
46
50 (6/4´´)
910x620x360
HP 1100 BLACK Inverter
45/35
11.5
8.6
6.5
10.9-5.9
0.2-1.9
-7°C...+43°C
3.3
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.5
50
50
932x609x377
HP 1100 GREEN Inverter Pro
65/30
10.8
7.7
4.5
4.5-14
0.20-1.71
-15°C...+43°C
3-5
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.52
42.8
50 (6/4´´)
990x657x340
HP 1400 GREEN On-Off
55/40
12.3
8.6
6.2
4.7-6.0
1.8
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
5.3
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.6
52
50 (6/4´´)
1000x665x385
HP 1500 BLACK Inverter
65/50
15.4
11.5
6.7
10.7-5.7
0.3-2.7
-7°C...+43°C
4.4
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.6
53
50
1015x766x427
HP 1500 GREEN Inverter Pro
80/40
15.0
10.5
6.7
4.6-15
0.27-2.28
-15°C...+43°C
5-7
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.72
45.5
50 (6/4´´)
990x657x340
HP 1700 GREEN On-Off
70/50
16.2
11.3
8.3
4.7-6.0
2.4
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
7.1
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
-
54
50 (6/4´´)
1000x665x385
HP 1700 Green Inverter Pro
95/45
17.0
11.5
7.5
4.6-15
0.29-2.5
-15°C...+43°C
6.5-8.5
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.8
46
50 (6/4´´)
954x648x429
HP 2100 GREEN Inverter Pro
105/50
21.0
14.5
9.5
4.6-14.8
0.41-3.15
-15°C...+43°C
8-10
230V/1pH/50Hz
Titanium Gr 1 ASTM B265
0.9
45.9
50 (6/4´´)
954x748x429
HP 2300 Inventor
80/60
23.0
17.6
17.5
5.4-6.0
3.5-5.5
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
8-10
400V/3pH/50Hz
Titanium Gr 1 ASTM B265
0.95
56
50 (6/4´´)
940x1550x360
HP 2400 Premium
80/60
24.4
18.7
21.7
6.3-6.9
3.51
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
8-10
400V/3pH/50Hz
Titanium Gr 1 ASTM B265
1.2
56
50 (6/4´´)
942x1550x360
HP 2700 GREEN Inverter Pro
135/60
27.5
18.0
11.9
4.6-15
0.48-3.91
-15°C...+43°C
10-12
400V/3pH/50Hz
Titanium Gr 1 ASTM B265
1.0
47.9
50 (6/4´´)
1084x948x429
HP 2800 INVENTOR
120/80
28.4
22.9
25.0
5.4-6.0
4.2-7.0
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
8-12
400V/3pH/50Hz
Titanium Gr 1 ASTM B265
1.2
56
50 (6/4´´)
940x1550x360
HP 3000 PREMIUM
120/80
30.1
24.3
26.8
6.3-6.9
4.34
-5°C...+43°C, s príslušenstvom: -15°C...+60°C
8-12
400V/3pH/50Hz
Titanium Gr 1 ASTM B265
1.4
56
50 (6/4´´)
942x1550x360

Výrobca si vyhradzuje právo na zmenu technických údajov bez predchádzajúceho upozornenia.
